PCI-DAS6013 and PCI-DAS6014 User's Guide

Power Consumption

+5V
+5V available at I/O connector

Environmental

Operating Temperature Range
Storage Temperature Range
Humidity

Mechanical

Card dimensions

Main Connector and Pin Out

Connector type
Compatible Cables
Compatible accessory products
(with C100HD50-xx cable)
Compatible accessory products
(with C100MMS-x cable)
0.9A typical, 1.1A max. . Does not include power consumed
through the I/O connector.
1A max, protected with a resettable fuse
0 to 55°C
-20 to 70°C
0 to 90% non-condensing
PCI half card: 174.4mm(L) x 100.6mm(W) x11.65mm(H)
Shielded SCSI 100 D-Type
C100HD50-x, unshielded ribbon cable. x = 3 or 6 feet
C100MMS-x, shielded round cable. x = 1, 2 or 3 meters
ISO-RACK16/P
ISO-DA02/P (PCI-DAS6014 only)
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
6-10
Specifications
