Accuracy

200 kS/s sampling rate, single channel operation and a 15-minute warm-up.
Accuracies listed are for measurements made following an internal calibration. They
are valid for operational temperatures within ±1°C of internal calibration temperature
and ±10°C of factory calibration temperature. Calibrator test source high side tied to
Channel 0 High and low side tied to Channel 0 Low. Low-level ground is tied to
Channel 0 Low at the user connector.
Range
±10V
±5V
±500mV
±50mV
Range
±10V
±5V
±500mV
±50mV
1
Averaged measurements assume averaging of 100 single-channel readings
Each PCI-DAS6014/6013 is tested at the factory to assure the board's overall error
does not exceed accuracy limits described in Tabl
All Ranges
No Missing Codes

System Throughput

Condition
1. Single channel, single input range
2. Multiple channel, single input range
3. Single channel, multiple input ranges
Note: For conditions 1-2 above, specified accuracy is maintained at rated throughput.
Condition 3 applies a calibration coefficient which corresponds to the range value
Table 6-1 – Absolute Accuracy
Absolute Accuracy
±29.4 LSB
±13.1 LSB
±30.9 LSB
±45.2 LSB
Table 6-2 – Absolute Accuracy Components - All values are (±)
% of Offset
Reading (µV)
0.070 1800
0.020 918
0.070 109
0.070 27
Table 6-3 – Differential non-linearity
±0.5 LSB typ ±1.0 LSB max
16 bits, guaranteed
Averaged
Temp Drift
Noise +
Quantization
(%/DegC)
1
(µV)
180 0.001
85 0.001
12 0.001
7 0.001
e 6-1
Calibration Coefficients
Per specified range
Per specified range
Default to value for
cbAInScan() range parameter
6-2
Absolute
Accuracy at FS
(mV)
8.984
2.003
0.471
0.069
above.
ADC Rate (max)
200 kS/s
200 kS/s
200 kS/s
Specifications
