(Optional) Mounting and Connecting the External Antenna

Step 2: Attach the Dynamic Bracket to the Access Point
9
(Optional) Mounting and Connecting the
External Antenna
If you want to extend the range of your wireless network, you can connect a 2.4GHz 9dBi
(or lower) external antenna to the standard N-type female connector on the Access Point.
WARNING: Only trained and qualified personnel should be allowed to install, replace,
or service this equipment.
WARNING: Before connecting the antenna to the Access Point, make sure that you
disconnect the Access Point from the power source.
1. Disconnect the Access Point from the power source.
2. Unscrew the metal cap that protects the antenna connector. Place the metal cap in a
safe place, in case you need it later.
3. Connect the antenna to the standard N-type female antenna connector.
If the antenna comes with an RF coaxial cable (for example, a patch antenna), do the
following:
a. Physically mount the antenna on your desired location, preferably on the same
supporting mounting structure as the Access Point.
b. Connect the RF coaxial cable to the standard N-type female connector on the
Access Point.
