Ruckus Wireless ZoneFlex 2741 802.11g Getting Started Manual page 43

WARNING: Do not apply power to the Access Point until you finish connecting all other
components.
1. Take the Access Point to its mounting location.
2. Verify that the Cat5e FTP cable (outdoor-rated) from the Access Point is long enough
to reach the PoE injector that is installed indoor.
3. Install an Ethernet surge protector between the Access Point and the PoE injector
where the cable enters the building (as shown in
cables for the connections.
4. Create a drip loop in any cable that is attached to the Access Point and Ethernet surge
protector. This will prevent water from running along the cable and entering the Access
Point, Ethernet surge protector, or the building where the cable terminates.
5. Verify that the RJ45 port on the AP is connected to the PoE OUT port on the PoE
injector.
6. Connect the Ethernet cable from the 10/100 DATA IN port on PoE injector to your
network router or switch.
7. Apply power to the Access Point.
• If you are using PoE, plug the power adapter to an AC power source.
• If you are using DC power, connect the DC cable to a DC power source.
NOTE: If the power outlet in your installation environment is three-pronged, use the two-
prong plug adapter that is shipped with the Access Point.
8. Verify that the PWR LED on the back of the Access Point is steady green.
9. Continue to "Attaching the Mounting
Deploying the Access Point
Step 3: Connect the Access Point to the Network
Figure 25). Use outdoor-rated Ethernet
Brackets".
39
