Mounting the Access Point
Step 2: Attach the Dynamic Bracket to the Access Point
Figure 34.
2. Align the mounting holes on the dynamic bracket with the mounting holes on the static
bracket.
3. Place a split lock washer, and then a flat washer onto a hex bolt. Then insert the hex
bolt into one of the mounting holes.
NOTE: Make sure the screw-washer assembly is in correct order. The split-lock washer
should be in the middle and the flat washer should touch the bracket.
4. Repeat Step 3 for each of the mounting holes. There are four mounting holes on the
bracket – two on each side.
48
Joining the two brackets in a vertical pole installation
