Use DC Power
To use DC to power the Access Point, you need to connect a DC cable (not supplied with
the Access Point) to the DC terminal block.
1. Take out the DC terminal block from the small plastic bag that contains the bottom
cover of the Access Point.
2. Connect the DC cable's ground wire to V- terminal. If you are looking at the terminal
block with the wiring terminal screws on top, the V- terminal is on the left side.
3. Connect the DC cable's +12v DC wire to the V+ terminal. If you are looking at the
terminal block with the wiring terminal screws on top, the V+ terminal is on the right
side.
Figure 22. Connect the ground wire to the V- terminal and the +12v DC wire to the V+
terminal
Ground Wire to
V- Terminal
4. Using a 3mm Phillips screw, tighten the wiring terminal screws. Screw torque value must
be 4kg-5kg.
5. Connect the DC terminal block to the 12V DC port on the Access Point.
WARNING: Do not apply power to the Access Point at this point. You should connect the
Access Point to a power source only after you finish connecting all other components in
"Step 3: Connect the Access Point to the Network"
Deploying the Access Point
Step 1: Complete the Power Connections
12V DC Wire to
V+ Terminal
on page 38.
