Attaching the Mounting Brackets
Step 1: Attach the Static Bracket to the Mounting Surface
9. Using a 10mm open-end wrench, tighten the nuts to secure the bracket to the
mounting surface. Screw torque value must be 4kg-5kg. As you tighten the nuts, the
metal cones that are built into the wall anchors will expand and lock the wall anchors
into place.
10. Continue to

Attaching the Bracket to a Pole

The Access Point can be mounted vertically or horizontally on a 30mm to 60mm (1.18 in.
to 2.36 in.) pole.
1. Insert the open end of the steel clamp into the two tabs on the bracket.
Figure 30.
44
"Step 2: Attach the Dynamic Bracket to the Access
Insert the steel clamp into the two tabs on the bracket
Point".
