Ruckus Wireless
™
Outdoor Access Point
Release 100.0.0 User Guide
For the following Ruckus Wireless Outdoor Access Points:
- SmartCell 8800-S Outdoor Access Point
- ZoneFlex 7762, 7762-AC, 7762-S, 7762-S-AC and 7762-T Dual-Band 802.11n APs
- ZoneFlex 7781CM Dual-Band 802.11n AP with Integrated Cable Modem
- ZoneFlex 7782, 7782-E, 7782-N and 7782-S Dual-Band 802.11n APs
- ZoneFlex T300 and T300e Omni 802.11ac Outdoor Access Points
- ZoneFlex T301n 30-Degree Narrow Sector 802.11ac Outdoor Access Point
- ZoneFlex T301s 120-Degree Wide Sector 802.11ac Outdoor Access Point
Part Number 800-70725-001 Rev B
Published 26 February, 2015
www.ruckuswireless.com
