Fractal Audio Systems MFC-­‐101 Manual
15 Specifications
GENERAL
Presets:
Songs:
Sets:
Bank Sizes:
Bank Styles:
PRESET MIDI DATA
Program Changes:
Custom MIDI Message:
Internal Control Change:
Control Change Numbers:
Control Change Data:
INSTANT ACCESS SWITCHES
Quantity:
Control Change Messages:
Control Change Numbers:
Control Change Data:
Program Change:
Program Range:
Custom MIDI Message:
MIDI INTERFACE
Output Connector:
Input Connector:
EXTERNAL SWITCH INTERFACE
External Switch Inputs:
Connectors:
Format:
EXPRESSION PEDAL INTERFACE
Expression Pedal Inputs:
Connectors:
Compatibility:
AXE-­‐FX PORT
Connector:
Interface:
FASLINK PORT
Connector:
MECHANICAL/ELECTRICAL
Chassis:
LCD:
Dimensions:
Weight:
Input Voltage:
Power Consumption:
ENVIRONMENTAL
Operating Temperature:
Storage Temperature:
Humidity Max.:
(Specifications subject to change without notice)
Doc v3.0
384
100, up to 15 presets in each song
10, up to 50 songs in each set
0-­‐17 (Specifies the number of footswitches in 17 which select presets)
Current, First, None
16 (1 per channel. Axe-­‐Fx Mode overrides one of these)
Up to 16 bytes
17
0–127, OFF
Independently programmable ON and OFF values (0–127 or OFF)
17
2
0–127, OFF
Independently programmable ON and OFF values (0–127 or OFF)
1 each for ON and OFF states
0-­‐999 or OFF (Bank Select CC#0 messages are automatic.)
Up to 16 bytes each for ON and OFF states
7-­‐pin DIN (pins 6 and 7 connected to phantom power in jack)
5-­‐pin DIN (pins 1 and 3 connected to MIDI In for 2-­‐way data from a single port)
4
2 x ¼" TRS phone jacks (2 switches per connector)
Compatible with Toggle or Momentary switches
4
¼" TRS phone jacks (1 expression pedal per connector)
Expression type (not Volume pedals), 10K–100K recommended max resistance
RJ45 Ethernet/EtherCON
RS-­‐422
XLR Male type
Powder-­‐coated 16-­‐gauge steel
1×20 dot matrix transflective LCD display
Footprint: 15.75" W x 10" L (400 x 254 mm)
Height from bottom of foot to top of front switch: 3" (76 mm)
Height from bottom of foot to top of rear switch: 4 1/16" (105 mm)
10 lbs. (4.5 kg)
9 VAC, 47 -­‐ 63 Hz (AC adapter input specific to region where the unit was purchased).
<10 W
32 to 122°F (0 to 50°C)
-­‐22 to 167°F (-­‐30 to 70°C)
90% non-­‐condensing
