14.6 Specifications

GENERAL
Presets:
Songs:
Sets:
Bank Sizes:
Bank Styles:
PRESET MIDI DATA
Program Changes:
Custom MIDI Message:
Internal Control Change:
Control Change Numbers:
Control Change Data:
INSTANT ACCESS SWITCHES
Quantity:
Control Change Messages:
Control Change Numbers:
Control Change Data:
Program Change:
Program Range:
Custom MIDI Message:
MIDI INTERFACE
Output Connector:
Input Connector:
EXTERNAL SWITCH INTERFACE
External Switch Inputs:
Connectors:
Format:
EXPRESSION PEDAL INTERFACE
Expression Pedal Inputs:
Connectors:
Compatibility:
EXPANSION PORT
Connector:
Interface:
MECHANICAL/ELECTRICAL
Chassis:
LCD:
Dimensions:
Weight:
Input Voltage:
Power Consumption:
ENVIRONMENTAL
Operating Temperature:
Storage Temperature:
Humidity Max.
(Specifications subject to change without notice)
Doc v1.0.1
128
100, up to 15 presets in each song
10, up to 50 songs in each set
1, 5, 10, or 15
Current, First, None
16 (1 per channel. Axe-Fx Mode overrides one of these)
Up to 16 bytes
17
0–127, OFF
Independently programmable ON and OFF values (0–127)
Up to 17 (IA Switches 18-41 appear in the software but are reserved for future use)
2
0–127, OFF
Independently programmable ON and OFF values (0–127)
1 each for ON and OFF states
OFF
0-999, (uses Bank Select CC#0)
Up to 16 bytes each for ON and OFF states
7-pin DIN (pins 6 and 7 connected to phantom power in jack)
5-pin DIN (pins 1 and 3 connected to MIDI In for 2-way data from a single port)
4
2 x ¼" TRS phone jacks (2 switches per connector)
Compatible with Toggle or Momentary switches
4
¼" TRS phone jacks (1 expression pedal per connector)
Expression type (not Volume pedals), 10K–100K recommended max resistance
RJ45
RS-422
Powder-coated 16-gauge steel
1×20 dot matrix transflective LCD display
15.75" x 3" x 10" (400 x 76 x 254 mm)
10 lbs. (4.5 kg)
9 VAC, 47 - 63 Hz (universal input)
<10 W
32 to 122°F (0 to 50°C)
-22 to 167°F (-30 to 70°C)
90% non-condensing
APPENDIX
73
