Fractal Audio Systems MFC-‐101 Manual

12.4 The MIDI Menu

The MIDI menu is used to set parameters which determine the MIDI output of the MFC-‐101.

12.4.0 MFC-‐101 Port

EDIT : MIDI

Axe-‐Fx MIDI Channel is used to set the port ove which the MFC-‐101 and Axe-‐Fx will communicate. "Expansion" refers to the

Ethernet/EtherCON port. FASLINK is the FASLINK port, available only on the MFC-‐101 Mark III or newer.

12.4.1 Axe-‐Fx MIDI Channel

EDIT : MIDI : PAGE"

(1x)

Axe-‐Fx MIDI Channel is used to set the channel on which the MFC-‐101 and Axe-‐Fx will communicate. For AXE-‐FX MODE to

work properly, this setting must match that of the Axe-‐Fx under I/O : MIDI : MIDI CHANNEL.

12.4.2 Axe-‐Fx TotalSync

EDIT : MIDI : PAGE"

(2x)

Axe-‐Fx TotalSync causes the MFC-‐101 to follow presets loaded via the front Panel of the Axe-‐Fx II or Axe-‐Edit.

TotalSync is designed for basic, default MFC/Axe-‐Fx II interactions only:

MFC-‐101 SONG and SET modes are not supported.

•

Custom MFC-‐101 Tx Map or Axe-‐Fx II preset remapping are not supported. (Presets loaded from the Axe-‐Fx II front

•

panel will load in their default MFC-‐101 bank/footswitch locations despite re-‐mapping.)

Axe-‐Fx Standard and Ultra are not supported.

•

Axe-‐Fx II firmware version 6.0 or better is required.

•

Doc v3.0

MIDI MENU REFERENCE
