MIDI MENU REFERENCE
12.4.3 Axe-­‐Fx Preset Transmit Map
EDIT : MIDI : PAGE"
(3x)
The Axe-­‐Fx Preset Transmit ("Tx") Map is used to set up a custom map between MFC-­‐101 presets and Axe-­‐Fx presets. This
makes it possible for any MFC-­‐101 preset to load any of the 384 presets from a connected Axe-­‐Fx.
PARAMETER
" footswitches to select between MFC Preset and Axe-­‐Fx Preset.
Use the !
The value "OFF" causes the current preset to send no change to the Axe-­‐Fx, which allows you, for example, to change presets
on other components without switching the preset of a connected Axe-­‐Fx.
12.4.4 MFC-­‐101 MIDI Receive Channel
EDIT : MIDI : PAGE"
(4x)
MFC-­‐101 MIDI Receive ("Rx") Channel is used to specify the channel on which the MFC-­‐101 will respond to MIDI program
change messages received at its MIDI IN port, if this feature is enabled (see below).
12.4.5 MFC-­‐101 Receive Program Change
EDIT : MIDI : PAGE"
(5x)
MFC-­‐101 Receive ("Rx") Program Change is used to enable or disable incoming MIDI Program change response on the MFC-­‐
101. Enabling this setting allows other devices to remote control the MFC-­‐101 by loading its presets, which in turn send the
usual MIDI instructions to the MIDI OUT port as if they had been selected via footswitch.
12.4.6 MFC-­‐101 Program Change Map
EDIT : MIDI : PAGE"
(6x)
The MFC-­‐101 Program Change Map is used to create a custom relationship between incoming MIDI program change messages
and MFC-­‐presets. This makes it possible to recall different MFC-­‐101 presets depending on the MIDI program change number
received.
PARAMETER
! " footswitches move between Incoming Program Change and MFC Preset Number parameters.
NOTE: The range of MFC-­‐101 Preset Numbers shown will be affected by the MFC-­‐101 Display Offset (12.5.3).
NOTE: Receive Program Change (12.4.5) must be enabled for the MFC-­‐101 to respond at all to Program Changes.
