BASIC SETTINGS

3 BASIC SETTINGS

3.1 Axe-‐Fx Mode

AXE-‐FX MODE makes using the MFC-‐101 easier and more intuitive. Axe-‐Fx mode rides on top of PRESET, SONG, or

SET mode to provide a number of benefits when using the MFC-‐101 with an Axe-‐Fx II, Ultra, or Standard.

! Axe-‐Fx preset names are displayed dynamically as they load—no need for data entry or import!

! Instant Access Switch Axe-‐Fx Functions can be set simply by selecting from a list.

! Instant Access Switch LEDs show the effects in the current Axe-‐Fx preset when it is loaded:

GREEN: Present & Active; RED: Present & Bypassed

! The TAP TEMPO footswitch LED flashes the current Axe-‐Fx tempo.

! The TUNER footswitch displays the Axe-‐Fx tuner in the MFC-‐101 display.

! Preset footswitches can also send general use MIDI commands for controlling bigger rigs.

! Individual IA Switches can be set up with general use MIDI commands instead of Axe-‐Fx functions.

You may wish to refer to p. 74 of the appendix to view the Comparison Table: AXE-‐FX MODE ON vs. OFF.

3.1.1 Enabling/Disabling Axe-‐Fx Mode

For Axe-‐Fx mode to work, you must initially select the Axe-‐Fx model you are using with the MFC-‐101. If you are

using the MFC-‐101 without an Axe-‐Fx, you should turn Axe-‐Fx mode OFF.

Press EDIT footswitch to enter EDIT MODE

Press SETUP footswitch for the SETUP menu to arrive at the AXE-‐FX MODE screen:

Press the INCR or DECR footswitches to select the model of AXE-‐FX MODEL you are using, (II,

ULTRA, STANDARD) or select OFF to disable Axe-‐Fx mode.

As of MFC-‐101 firmware version 2.0, the default is Axe-‐Fx II.

Press EXIT to return to PERFORMANCE MODE.

! IMPORTANT: Axe-‐Fx Mode requires Axe-‐Fx firmware dated AUGUST 2010 or later. Check your unit under UTILITY:FIRMWARE

and visit http://www.fractalaudio.com/support to download a free upgrade if required.

To improve usability for individuals with red/green colorblindness, red LEDs can be set for "OFF". See p. 66.

Fractal Audio Systems MFC-‐101 Manual

; OFF: Not Present.

Doc v3.0
