INTERNAL CCs
It is not possible to display the Axe-­‐Fx Tuner on the MFC-­‐101 when Axe-­‐Fx Mode (p. 12) is turned off, though a CC#
message can still turn the tuner on and off in the same way it would work on any other MIDI Foot Controller.
A special function allows the tap footswitch to launch the Axe-­‐Fx TUNER when held. See section 12.5.20.
5.2 General Use IA Switches
Instant Access Switches with their Axe-­‐Fx functions set to "NONE" (or all IA switches when Axe-­‐Fx mode is OFF)
offer a set of powerful general use MIDI commands. These General Use IA Switches can send the following types
of MIDI instructions when turned ON:
Up to 2 different MIDI Control Change messages with custom values (0–127).
•
Any one MIDI program change command on any channel.
•
Up to 16 bytes of freeform hexadecimal MIDI commands.
•
The OFF state can send:
The custom OFF values (0–127) for any CC#s sent by the ON action.
•
Any one MIDI program change command on any channel.
•
Another 16 bytes of freeform hexadecimal MIDI commands.
•
! REMEMBER: When AXE-­‐FX MODE is ON, IA Switches with Axe-­‐Fx functions assigned will ONLY send the MIDI commands for
their Axe-­‐Fx assignments. See section 5.1, above.
The default assignments for the first Control Change message of each IA Switch are shown below. These are sent
with values of 127 for ON and 0 for OFF. All other IA switch settings are OFF by default.
Figure 5-­‐2: Default Control Change Assignments for General Use IA Switches.
5.2.1 General Use IA Switch Control Change Messages
Each IA Switch may be assigned up to 2 Control Change message numbers, each of which sends an ON value when
the switch is turned ON, and an OFF value when the switch is turned OFF.
