MIDI MENU REFERENCE
12.4.9 IA Switch Control Change ON/OFF Values
EDIT : MIDI : PAGE"
(9x)
IA Switch CC# ON/OFF Values is used to specify the ON and OFF data values for each of the two CC# commands of a selected
IA Switch.
PARAMETER
" footswitches to select from Instant Access Switch Number, Command Select, Data Value OFF, and
Use the !
Data Value ON parameters. IA Switch numbers 18-‐41 are reserved for future use.
This function allows you to use the onboard footswitches send any data value when turned ON or OFF. This makes it possible,
for example, to use an IA switch to toggle between volume levels of 100 and 127.
A setting of "OFF" for either state will cause it to send no data. This is useful for controlling functions where ANY incoming data
value is seen as a trigger (example: Axe-‐Fx Tempo, Axe-‐Fx VOL INCR/VOL DECR, etc.).
12.4.10 IA Switch Program Change Settings
EDIT : MIDI : PAGE"
(10x)
IA Switch Program Change Settings is used to specify a single Program Change command to be sent on a specified channel
when the selected switch is turned ON, and another such message for when the switch is turned OFF.
PARAMETER
" footswitches to move between Instant Access Switch Number, ON/OFF Command Select, Program
Use the !
Change Number, and MIDI Channel parameters. IA Switch numbers 18-‐41 are reserved for future use.
ON/OFF Command Select is used to switch between setting the Program Change that is sent when the IA Switch is turned ON,
and that which is sent when it is turned OFF.
To support program changes from 000-‐999 with a single parameter, the MFC-‐101 sends Bank Select (CC#0) messages followed
by a program change.
Program Range
Bank Select
000-‐127
0
128-‐255
1
256-‐383
2
384-‐511
3
The actual program change number that will be transmitted is the remainder (modulus) of the set value divided by 128. For
example, an MFC-‐101 Program Change setting of 200 will send a Bank Select of 1 (bank B) and a Program Change of 72.
(200/128=1 with a remainder of 72)
56
Program Range
512-‐639
640-‐767
768-‐895
896-‐999
Fractal Audio Systems MFC-‐101 Manual
Bank Select
4
5
6
7
PAGE
or !
(8x)
Doc v3.0
