Fractal Audio Systems MFC-­‐101 Manual
To set the CC# assignments for a switch:
1. Press EDIT footswitch to enter EDIT MODE.
2. Press MIDI footswitch to select the MIDI menu.
3. Press PAGE" 7x to get to the IA Switch CC# Settings screen:
4. Tap and/or hold the INCR or DECR footswitches to select an IA Switch
5. Press PARAMETER" to move to the Command Select parameter.
6. Press INCR or DECR to select between CC Command 1 or CC Command 2.
(Each IA switch allows 2 different CC# messages, each with its own ON/OFF values).
7. Press PARAMETER" to move to the CC# Assign parameter.
8. Tap and/or hold the INCR or DECR footswitches to select a CC# assignment for the selected
command. Set this value to OFF to disable the selected command.
9. Press PARAMETER" to move to the MIDI Channel parameter.
10. Tap and/or hold the INCR or DECR footswitches to set a MIDI channel for the selected
command.
11. Press !PARAMETER 2x to return to step 5 to set up a 2
OR Press !PARAMETER 3x and select a different IA Switch to edit, OR press EXIT to return to
PERFORMANCE MODE.
The data values for IA switches is "0" for OFF and "127" for ON. The value of any switch state can be freely
changed to 0–127 or "OFF," which causes the switch state to send nothing. For more information on setting IA
data values, see IA Switch Control Change ON/OFF Values on p. 56.
5.2.2 Other General Use IA Switch Capabilities
! Each IA Switch can be programmed to send a Program Change when turned ON, and a second Program
Change when turned OFF. For more information, see IA Switch Program Change Settings on p. 56.
! Each IA Switch can send a 16 Byte custom MIDI message when turned ON, and a second custom
message when turned OFF. For more information, see IA Switch Custom MIDI Message on p. 57.
! Each IA Switches may be given a 7-­‐character name. This is displayed whenever the switch is turned
4
on , as a helpful reminder in EDIT mode when the NAMES footswitch is pressed while the cursor is in a
parameter used to select IA Switches by their numbers. See Chapter 11 for more information.
4
Axe-­‐Fx IA switches ignore their set names while Axe-­‐Fx mode is on, and display their function names instead.
Doc v3.0
nd
command for the selected IA Switch,
INTERNAL CCs
25
