SPECIFICATIONS
15.2 Midi Implementation Chart
NOTE: MFC-­‐101 Presets and Instant Access Switches have the capability to send custom MIDI data, entered
freeform as hex code, which can be used for many applications not supported "natively" (ex: Note On/Off).
Function
Default
Basic Channel Changed
Default
Mode Message
Altered
Note Number True Voice
Note ON
Velocity
Note OFF
Keys
After Touch
Channels
Pitch Bend
Control Change
True Number
Bank Select
Program Change
Fractal Audio
Real-­‐Time
Non-­‐Real-­‐Time
System Exclusive
Song Position
System Common Song Select
Tune Request
Clock
System Real-­‐Time
Commands
Local ON/OFF
All Notes OFF
Auxiliary Messages
Active Sense
Reset
0 = YES, X=NO
84
Transmitted Received
1 None
1-­‐16 1-­‐16
X X
X X
X X
O X
X X
X X
X X
X X
X X
O X
O O
O O
O O
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
Fractal Audio Systems MFC-­‐101 Manual
Remarks
The MFC-­‐101 is shipped with almost all MIDI messages disabled.
Exceptions are expression pedals 1 and 2, which are used for AXE-­‐FX
MODE. All settings are saved in persistent EEPROM.
Instant access switches can send two control change messages. Internal
control changes can send one control change. The control change values
for these messages default to 0 = Off and 127 = On and are configurable.
Custom MIDI messages can also be used to send control change.
Instant access switches can send one program change command per
switch state (off/on). Presets can send up to 16 program change
messages, one per MIDI channel. Program change numbers are
displayed with a range of 0 to 999 or 1 to 1000. Program change
numbers are decomposed into a bank/program combination that gets
transmitted as a bank select message and program change message. A
receive program change map is available as is a transmit program
change map specifically for Axe-­‐Fx. Custom MIDI messages can also be
configured to send program change.
MFC-­‐101 sends a leading bank select control change message for every
program change except those configured under custom MIDI message
menus.
The MFC-­‐101 receives Bank Select and Program Changes if this is
enabled (12.4.5). Incoming Bank Select messages alias around 384.
Presets can send one custom 16-­‐byte MIDI message, which can be a
system exclusive message. Instant access switches can send one custom
16-­‐byte MIDI message per switch state (off/on), which can be a system
exclusive message. These custom messages may be configured to send
the standard system exclusive messages marked with an X above. MFC-­‐
101 also uses system exclusive for data dump and load, firmware
updates, and Axe-­‐Fx synchronization.
Doc v3.0
