Fractal Audio Systems MFC-­‐101 Manual
12.5 The Setup Menu
The MFC-­‐101 will re-­‐synchronize with a connected Axe-­‐Fx if any Axe-­‐Fx-­‐related parameters have changed when
returning to Performance Mode from the Setup Menu with AXE-­‐FX MODE turned ON.
12.5.0 Axe-­‐Fx Mode
EDIT : SETUP
Used to turn Axe-­‐Fx mode ON by selecting a model (Standard, Ultra, Axe-­‐Fx II) or OFF by selecting "NONE".
12.5.1 Performance Mode
EDIT : SETUP : PAGE"
(1x)
Performance Mode is used to select one of three types of performance mode: Preset, Song, or Set.
INCR DECR
Press the or footswitches to select PRESET, SONG, or SET XX, where XX is the number of the Set which will be in
effect until the operating mode is changed.
In PRESET MODE, MFC-­‐101 Presets are mapped sequentially across the banks. Banks may be scrolled through in order using
the UP or DOWN footswitches.
SONG MODE replaces banks with SONGS, in which the presets assigned to each footswitch are selected by the user. 100
SONGS are accessed in order by their numbers using the UP or DOWN footswitches.
SET mode allows the order of songs to be rearranged in 10 different lists of 50 songs each. Setting the operating mode for Set
also requires you to choose which set should be in effect (by its number).
NOTE: Changing operating modes will cause MFC-­‐101 to load the first preset for the new mode.
12.5.2 Axe-­‐Fx Display Offset
EDIT : SETUP : PAGE"
(2x)
Axe-­‐Fx Display Offset is used to set up the MFC-­‐101 to show preset numbers correctly when the connected Axe-­‐Fx is using a
display offset (causing its presets to be numbered 1-­‐384 instead of 0-­‐383). The setting on this menu page must match that of
the Axe-­‐Fx under [IO]![MIDI]![DISPLAY OFFSET].
NOTE: This is purely a user interface setting and does not impact MIDI output.
Doc v3.0
SETUP MENU REFERENCE
61
