MCU Control GuidE
Main changes compared to the HUI front panel are:
New Function grouping to assign parameters the Channel D-Pots. CHANNEL is unchanged and assigns the AWS
channel gain element or DAW channel to the D-Pot according to the state of the Console Focus key. The Encoder
switch is used to 'flip' parameters on to the faders as before but now includes all processing parameters not just
send levels. The EDIT key is the standard MCU Edit (or Global View) command key, it does not affect the operation
of the channel SEL keys which can be flipped between the Ready(RDY) and Select(SEL) functions as per the HUI
mapping.
The Keys above the Motion controls are assigned to related transport functions as on the HUI interface.
EDIT EXT
GRID SYNC
RTZ MARKER
On screen tallies are provided for the Marker Key, together with a second tally for the MCU 'Rude Solo' indicator.
5 a - 1 6
AWS 900+ Owner's Manual
MEM PRE/
LINK POST
CYCLE PUNCH SELECT
SOLO
