The Master Control Panel

The Master Control Panel includes a mixture of master functions and modifier keys for control of a DAW.
AUX2
SEND
2
1
CHANNEL
PAN
Push to Flip
RDY
5
6
CHANNEL

Channel Banking Controls

The AWS 900+ console has 24 touch sensitive moving faders, however, if the DAW session has more faders than
this, the AWS 900+ can 'bank flip' its faders to control any number of virtual faders within the DAW.
To flip the 24 console faders to the next set of 24 DAW faders, press the right bank button. To flip back to the
previous 24 faders press the left bank button. Any number of virtual faders can be controlled from the AWS 900+
using the banking buttons.
To scroll the faders one at a time, press the CHANNEL button (located between the two banking arrow buttons)
followed by the left or right banking buttons; the CHANNEL button will light to indicate it is in 'Channel' mode. Press
the CHANNEL button once more to switch back to 'Bank' mode.

DAW Window Buttons

This group of keys provide instant access to the various windows within the DAW. Press them once to display or
hide the relevant menu.
ALT Opens or closes the floating window for the currently selected plug-in.
STATUS Opens or closes the Session Setup window.
TRANS Opens or closes the Transport window.
MEM Opens or closes the Memory Locations window.
MIX and EDIT Brings the window to the foreground. The button lights to show the currently active window.
3
INPUT
OUTPUT
ASSIGN
EDIT SEL
13
4
MUTE
UNDO
ESC
PRE/POST
SHIFT
BYPASS
7
CTRL
DEFAULT
SUSPEND
AUTO
8 11
6
AWS 900+ Owner's Manual
Master Control Panel
SAVE ALT
9
STATUS
ENTER
TRANS
OPTION
10
MEM
ALT
MIX
RDY
ALL
EDIT
12
13
5 - 3
