Setting Pre and Post Roll
Hold down ALT and press the PRE or POST button to highlight the left hand numeric field of the pre-roll or post-
roll time window. The time is displayed on the AWS 900+ TFT screen in place of the DAW position. The selected
numeric field will flash. Use the navigation left/right arrow keys to select a different numeric field if required, then
enter a value on the numeric keypad or use the Up/Down arrow keys to increase or decrease the selected field.
Press ENTER to confirm the time.
The CLR button on the numeric keypad can be use to clear the selected time.
20
Setting start (In) and end (Out) Times
Hold down ALT and press the IN or OUT button to highlight the left hand numeric field of the start or end time
window. The time is displayed on the AWS 900+ TFT screen in place of the DAW position. The selected numeric
field will flash. Use the navigation left/right arrow keys to select a different numeric field if required, then enter a
value on the numeric keypad or use the Up/Down arrow keys to increase or decrease the selected field.
Press ENTER to confirm the time.
The CLR button on the numeric keypad can be use to clear the selected time.
20
Audition
This function allows the IN, OUT, PRE and POST points to be checked.
Select the AUD button then press either the PRE, IN, OUT, or POST button. Press the AUD button again to cancel
the function..
When Audition mode is selected the transport section of the TFT screen displays audition in place of the Pre and
Post indicatiors.
PRE Plays from the pre-roll point to the selection start point
IN Plays from the selection start point for the post-roll time
OUT Plays from the end point less the pre-roll time to the end point
POST Plays from the selection end point for the post-roll time
ALT + OPTION + PRE or IN
ALT + OPTION + POST or OUT Plays from the selection end point to the selection end point plus post-roll time.
AWS 900+ Footswitch Control
The AWS 900+ has two 6.35mm jack footswitch connectors on the rear of the console (see Section 3). These are
intended for hands-free access to essential transport functions:
Footswitch Control One:
Either plays or stops the DAW. Holding down SHIFT will abort a recording if in record, or initiate half-speed
playback if stopped.
Footswitch Control Two:
Is used to activate or deactivate Record mode. Holding CTRL while pressing the foot switch will cycle through
record modes.
.
Plays from the selection start point less the pre-roll time to the selection start
time plus the post-roll time
