Input, Output and Send Routing
The channel D-Pots can also be used to assign signals to inputs, outputs and aux sends of your DAW mixer:

Viewing Input, Output and Send Routing

The Input, Output or Send routing for all DAW channels can be displayed on the channel scribble strip by holding
down the INPUT, OUTPUT or SEND button on the Master Control Panel. The Master Send D-Pot can be used to
select which of the available sends you wish to display.

Setting Input, Output and Send Routing

To make or change an Input, Output or Send assignment:
1. Select ASSIGN + INPUT or OUTPUT or SEND on the Master Control Panel.
When using SEND select which send you wish to change from the available send slots using the Master Send
2
D-Pot
2. The D-Pot scribble strip will now read ASGN and the fader scribble strip will indicate the current routing for the
DAW channel.
3. Turn a channel D-Pot to scroll through a list of available DAW inputs or outputs (names are derived from the
DAW I/O settings not the AWS 900+). The list will appear in the channel scribble strip. The green LED below the
D-Pot will flash.
4. Push the D-Pot knob to select the current assignment; the green LED will become solid and a '>' symbol will
appear in front of the assigned signal (for example, '>Out3-4').
5. Press the ASSIGN button once more to exit assign mode. This will also commit any changes made that have
not been confirmed by pressing the D-Pot.
6. Pressing ESC at any time will abort the assignment process.

Assigning Signals to Multiple Channels

Holding down OPTION then pressing any channel D-Pot will assign that channel's input to all channels.
Holding down SHIFT + OPTION will assign that channel's input to all selected channels. Select SEL mode on the
Master Control Panel then press the SEL buttons on the channels you wish to route to.
Holding down OPTION and ALT then pressing a channel D-Pot will incrementally route that channel's input to all
channels. For example, selecting input 1 as the input to channel 9, then holding down OPTION and ALT before
pressing the channel 9 D-Pot will route input 1 to channel 9, input 2 to channel 10, input 3 to channel 11 and so
on across the entire DAW.
Holding down SHIFT + OPTION+ ALT will incrementally route that channel's input to all selected channels. Select
SEL mode on the Master Control Panel then press the SEL buttons on the channels you wish to route to.

Assigning a Channel to Multiple Outputs

Hold the CTRL button and select another output. The currently assigned output will have a '>' symbol before it (for
example, '>Out3-4'), and other added outputs will have a '+' (for example '+Out5-6') until you assign it.
In the scribble strip, an '@' symbol indicates that an item is inactive (ie routed but muted). The '$' symbol indicates
that more than one output is assigned, and at least one of those is inactive.
