Solid State Logic AWS 900+ Owner's Manual page 89

MCU Control GuidE
AWS Nuendo Control Key Layout
AUX2
EFFECTS
CHANNEL
NAME
VALUE
Push to Flip
RDY EDIT
CHANNEL
The majority of Nuendo or Cubase functions are controlled via dedicated keys with virtually no reliance on the 8x8
key matrix located beneath the screen. Full details are available in the Mackie Control and Nuendo document
available from the Nuendo download page http://www.steinberg.de/439_0.html.
Major changes compared to the HUI front panel are the new control set for assigning processing parameters to the
D-Pots.
Up and down page keys for D-Pot parameters are located with the Shift key block. The rotary encoder will also
output the page up/down commands when turned left or right.
RDY and SEL control the function of the Channel SEL key as in the HUI interface. The EDIT key is used to open
editing windows in Nuendo or Cubase for the current selection. EDIT together with SHIFT will close an active
window.
CHANNEL is unchanged and assigns the AWS channel gain element or DAW channel to the D-Pot according to
the state of the Console Focus key. The Encoder switch is used to 'flip' parameters on to the faders as before but
now includes all processing parameters not just send levels.
5 a - 8
AWS 900+ Owner's Manual
INST MASTER
PLUG-IN
PAN
EQ SEND
SMPTE
SEL
BEATS
ESC
ENTER
SAVE
UNDO
SHIFT
READ WRITE
SOLO
MOTORS
PROJ
MIX
