XR622 X-Rack Master Module User's Guide
This documentation package contains the User's Guide for your new X-Rack Master
module. Depending on the age of your X-Rack, these pages may already be present in
your X-Rack Owner's Manual – please check to see if these pages match your Manual.
If they do not, these pages should be filed alongside it.
Please Note. The XR623 X-Rack Master module operates in conjunction with the XR625 X-Rack Mic Amp
and XR623 X-Rack Line Return modules.
X-Rack units prior to serial number XRK0110 are compatible with the X-Rack Master module
but may require a small modification to the buscard; if the 'SOLO' LED is permanently
illuminated, resistors R1 and R2 will need removing. In addition, any Mic Amp or Line Return
module(s) must be fitted immediately to the left of the Master module – later X-Rack units do
not have this limitation and modules may be freely placed anywhere in the later X-Rack units.
For correct operation of this module, your X-Rack unit must be running V1.2/0 or later
software. Please refer to your X-Rack Owners Manual for instructions on how to check the
current software version and how to obtain and install a newer version if required.
There may be a newer version of the X-Rack Owner's Manual available for download from our
website ( http://www.solid-state-logic.com )
