DAW Control GuidE
AUX2
SEND
2
1
CHANNEL
PAN
Push to Flip
RDY
5
6
CHANNEL

DAW Utility Buttons

This group of four buttons provide shortcuts to useful functions in the DAW.
SAVE will light when unsaved data is present. Pressing it once will cause the SAVE button to flash. A second press
will Save the Pro Tools session. Press ESC to cancel a pending Save.
The UNDO button will light if undo is available and flash if redo is available. Press the UNDO button to Undo the
last function and press ALT + SHIFT + UNDO to Redo the last function.
ENTER duplicates the function of the ENTER key on the computer keyboard.
ESC(ape) duplicates the function of the ESC key on the computer keyboard.
Modifier Buttons
These buttons modify the function of other buttons. Their function is detailed in the relevant sections of the manual.
OPTION typically changes the function of a single button to affect all similar buttons. Thus holding down OPTION
and pressing a channel CUT button will cut all DAW channels. It is a direct equivalent of the Macintosh Command
key.
SHIFT allows selection of multiple objects or controls. It is a direct equivalent of the computer keyboard Shift key.
ALT increases the resolution of rotary controls and inverts switch selections when held down. It is a direct
equivalent of the Macintosh keyboard Option key.
CTRL disengages grouping when held down. It is a direct equivalent of the Macintosh keyboard Ctrl key.
5 - 4
AWS 900+ Owner's Manual
3
INPUT
OUTPUT
ASSIGN
EDIT SEL
9
10
4
MUTE
UNDO
ESC
PRE/POST
SHIFT
BYPASS
7
CTRL
DEFAULT
SUSPEND
AUTO
8 11
SAVE ALT
9
STATUS
ENTER
TRANS
OPTION
10
MEM
ALT
MIX
RDY
ALL
EDIT
12
13
