Setting Sends Pre/Post Fader

When working with sends it is useful to be able to flip a send between pre and post fader.
If necessary select the PRE/POST button
Pushing a channel D-Pot will now switch the selected send on that channel between pre and post.
The green LED below the D-pot lights to show PRE is selected.
To change mode on all channels press and hold the OPT button then press any channel D-Pot. All channels will
switch to Pre or Post.
Muting a Send Output
To mute a send output select the MUTE button
green LED below the channel D-Pot will light to show the channel is muted.
16
SOLO
CUT
15
SndA
14
Gtr
18
SEL
17
SOLO CUT
19
5 - 1 0
AWS 900+ Owner's Manual
3
4
INPUT
OUTPUT
ASSIGN
EDIT SEL
4
To mute or un-mute all channels press and hold the OPT button then press any
channel D-Pot. All channels will mute or un-mute.

Flipping Send Levels to the Faders

To flip Send levels from the D-Pots to the channel faders, press the Master Send
D-Pot 2 marked 'Push to Flip').
The channel faders now control the send levels and the fader CUT button will
mute the send.
The channel D-Pot controls panning on stereo sends.
In this mode PRE/POST mode is automatically selected for the D-Pot switches, so
pushing a D-Pot will toggle the Send pre/post selection on that channel. The green
LED below the D-Pot lights to show PRE is selected.
The fader SOLO button will solo the channel, not the send.
4
MUTE
UNDO
ESC
PRE/POST
SHIFT
BYPASS
7
DEFAULT CTRL
SUSPEND
AUTO
8 11
on the Master Control Panel.
