Solid State Logic AWS 900+ Owner's Manual page 118

Setup Menu
The Setup menu contains various options for the mix system. To display the Setup menu end your Mix Pass,
deselect the List Mix Key and press the Setup key. Scroll to the option to be edited and select using the left D-
Pot push switch. Once the option is active, the left D-Pot will increment/decrement a numerical value as it is turned
or page through the various option states. Press the D-Pot push switch a second time to complete the setup
operation.
Glide Frames - Sets the ramp time in frames for Snap mode. The range is from 0 (no glide) to 255 (10 second
glide).
Rollback Threshold frames - Sets the number of consecutive descending frames that the systems needs to see
to determine if a rollback has taken place. The range is 2-10 and the default is 2 frames. Increase as required if
a rollback occurs on stopping the timecode master.
Latched Match & Play - Normally Match and Play are automatically deselected after a Cut switch is operated.
This option latches the Match or Play function until deselected manually.
00: 02: 12: 23 M i x Enabl ed
Glide frames: 10
Rollback Threshold frames: 5
Latched Match and Play: No
Setup
Misc
TR Auto
Lnks
Trim Moff TLock Snap
A
SSL
AT CS
Match Play
AWS 900+ Owner's Manual
AWSomation
7 - 1 1
