Transport Controls - Solid State Logic AWS 900+ Owner's Manual

Shuttle/Scrub Wheel
A dual-concentric Shuttle/Scrub wheel is provided. It has a spring-loaded outer ring and a continuously variable
inner wheel for scrub and shuttle functions for the DAW. The wheel can also be used to make and adjust selections
on the DAW.
Using the Shuttle Wheel
When the DAW is stopped, turn the wheel to activate shuttle mode. The outer rim will step through seven fixed
shuttle speeds, while the inner controller is continuously variable.
Using Scrub Mode
Select a region to scrub within your DAW. Press the SCRUB button next to the wheel. The inner wheel now
becomes an analogue tape machine style scrub wheel for the DAW.
Using the Numeric Keypad to shuttle
Depending upon the configuration of your DAW system, the numeric keypad
speed and direction. Hold down the CTRL button followed by a number on the numeric keypad that represents the
shuttle speed. The +/- buttons control the direction of shuttle.
Exit from Scrub/Shuttle Mode
To exit from shuttle mode press either the STOP or ESC button.
Notes on Scrub and Shuttle Modes
The position at which the scrub/shuttle starts is derived from the current DAW selection or timeline position.
Scrub/Shuttle mode can commence from the selection end point by holding down the OPTION button before you
you grab the shuttle wheel.
Holding down the ALT button will increase the resolution of the scrub/shuttle wheel.
When scrub or shuttle is active, many functions are suspended until you exit from scrub/shuttle mode. The following
functions are available:
Fader control, solo and cut buttons
Scrub/Shuttle wheel functions

Transport controls

Enter button (to create marker/cue events)
Scrub/Shuttle will also control serial machines if the DAW is 9-pin enabled.
Numeric Keypad
The console's numeric keypad replicates the numeric keypad on your DAW keyboard. The primary use for this
keypad is for saving and recalling Memory Locates and entering data values (please refer to your DAW manual for
more details on keypad uses)
Working with Markers/Memory Locations
To Enter a Marker/Cue point – press ENTER.
To Recall a Marker/Cue point – press a number followed by the decimal point button (Numeric Keypad in Classic
mode) or a decimal point followed by a number followed by the decimal point button (Numeric Keypad in Transport
mode).
Note: The ENTER button on the keypad also works as a enter button for pop-up windows, duplicating the ENTER
button on the Master Control Panel.
24
23
Motion Control Panel
23
can be used to control shuttle
