Remove the fixing screw (see figure above). Withdraw the power-supply and carefully unhook the
connectors for power and fan (see figure below) before completely removing the power-supply
module.
Power connector
Fan power cable

Figure C.7. Fan power.

After removing the power-supply, insert the replacement unit carefully the same way, reconnect the 2
cables, fasten the fixing screw and re-mount the back plate. Then pack the defective power supply in
the same box you received the replacement power supply and return it to your support center.
