Once the unit has completed the initialization processes, the Default screen as shown in Figure 4.3,
appears and the loader is ready for SCSI/SAS commands.
The Map of the cartridges has the following symbols:
1. A "?" when status is unknown and Inventory is still running.
2. A number indicates a slot occupied by a cartridge. To cartridge slot numbering is shown in
Figure 2.3.
3. Underscore line "_"indicates an empty slot.
4. "C" indicates that a Cleaning Cartridge occupies the slot.
The line below the map on the default screen gives the drive status. The drive status displayed is
drive-dependent.
Line 2

Figure 4.3. The Default screen.

The possible robot operation statuses are shown in Table 4.1 below.
# Operation Status
1 Idle
2 Fetching
3 Stowing
4 Moving

Table 4.1. Robot Operation Statuses.

28
Robot operation
status
Idle
Map: __3_5_7_
Drive Empty
Description
The loader is idle
The loader is moving a cartridge from a magazine slot or
from the drive to the robot.
The loader is moving a cartridge from the robot to a
magazine slot or to the drive.
The loader is moving the robot.
Menu button
Soft Label
Menu
Chapter 4. Operation and Configuration.
