Figure 8.2. Example of detailed information.

Figure 8.3. Example of further detailed information.

In this example, pressing the "Back" button twice takes you back to the Error Code Page (see Figure
8.1) where you can press "Actions" to go to the Actions menu. Figure 8.4 shows an example of
pressing "Actions". Pressing the buttons next to the up/down arrows on the screen gives you access
to other action options.

Figure 8.4. Example of action.

In Figure 8.4, you have been prompted to reboot the Loader. Pressing "Select" will result in the
warning message shown in Figure 8.5. Press "OK" to execute the reboot.

Figure 8.5. Warning message concerning reboot.

When an error condition occurs, identify the problem using the displayed error codes and follow the
suggested actions. The error codes are listed in Chapter 8.7. Error Codes.
71 StorageLoader Installation and User Manual
Reboot the Loader
and retry the
operation.
More Back
If the problem
persists please call
technical support.
Back
▲ Exit
Reboot
▼ Select
You are about to
reboot the loader
AND the drive !
Cancel OK
