2 Line Power Cords: one for USA/Japan and one for European power outlets
•
1 SCSI Interface Cable
•
1 SCSI Terminator LVD/SE EXT Male
•
1 Ethernet cable
•
Tool for Emergency Magazine Release
•
30 StorageLoader specific Bar code labels
•
A Rack Mounting Kit
•
Left and Right Rail Assembly
•
Screw M6x12 (6 pieces)
•
Screw M5x8 (1 piece)
There will be variations of this list.
Note

3.1.2. Step 2. Installing the StorageLoader in a Rack

The StorageLoader is designed for use in 19" rack system using 1U of rack space. The length of the
power cord and the SCSI cable may restrict the placement.
Attention: The StorageLoader is designed to operate in a horizontal position. Do not attempt to
operate the StorageLoader in any other position than horizontally. Also make sure that:
•
The airflow around the front and back of the StorageLoader is not obstructed.
•
There is a minimum of 60 cm free space in front of the unit to allow the operator to safely
remove the magazines.
•
The display and operator controls are easily accessed.
•
The StorageLoader is away from the floor, and in a clean environment with temperature within
specification. Appendix A. Specifications.
Do not attempt to operate the StorageLoader in any other position than
Caution
horizontally.
Recommended mounting tools:
•
Folding rule or tape measure
•
Screwdriver
•
7 mm open-end wrench
The rails are mounted to the loader during transportation. Before mounting the
Note
rails into the rack, dismount the rails from the loader and remove the spacers
between the rails and the loader.
