4.6.3. Set Password

If you set a password, make sure you do not forget it. If you do, it can only be
Caution
cleared with assistance from Tandberg Data technical support or by a qualified
service technician.
Item name
Set Password

Table 4.17. Setting Password.

4.7. Cartridge Handling

4.7.1. Cartridge Slot Numbers

The cartridge slots have been given numbers as follow: (see also Figure 2.3. Internal components of
the StorageLoader.)
•
Left magazine: Slot 1, Slot 2, Slot 3 and Slot 4 (lowest number closest to the front)
•
Right magazine: Slot 5, Slot 6, Slot 7 and Slot 8 (lowest number closest to the front)

4.7.2. Moving Cartridges to and from the Drive

The normal operations of the unit are controlled by the host software application. When you must load
or unload a specific cartridge using the control buttons on the front panel, do the following:
Loading a cartridge to the drive
1. From the default display press the menu button and select "Load to Drive" from the main
menu. A screen like Figure 4.11 appears. If a Barcode reader is implemented, the selected
cartridge's barcode is displayed in the bottom line.
2. Select the slot number of your choice. The system ignores empty slots. Press the "4 4 4 4 " button
to increment and the "3 3 3 3 " button to decrement.
3. Press the "OK" button.
The robot removes the cartridge from the selected magazine slot and moves it to the drive.

Figure 4.11. Load to Drive.

40
Description
Allows the operator to set a four-digit password protection for the menu
system. The default password is <0000>, meaning the password is
disabled.
OK
Load to drive
From Slot: 135
3 3 3 3
Cancel
4 4 4 4
Chapter 4. Operation and Configuration.
