4.6.3 Set Password

Item name
Set Password
WARNING: If you set a password, make sure you do not forget it. If you do, it can only be
cleared with assistance from Tandberg Data technical support or by a qualified service
technician.

4.7 Cartridge Handling

4.7.1 Cartridge Slot Numbers

The cartridge slots have been given numbers as follow: (see also Figure 2.3 Internal
components of the StorageLoader)
Left magazine: Slot 1, Slot 2, Slot 3 and Slot 4 (lowest number closest to the front)
Right magazine: Slot 5, Slot 6, Slot 7 and Slot 8 (lowest number closest to the front)

4.7.2 Moving Cartridges to and from the Drive

The normal operations of the unit are controlled by the host software application.
When you must load or unload a specific cartridge using the control buttons on the
front panel, do the following:
To load a cartridge to the drive:
1. From the default display press the menu button and select Load to Drive from
the main menu. A screen picture like figure 4.11 will be displayed. If a Barcode
reader is implemented, the selected cartridge's barcode is displayed in the
bottom line.

Figure 4.11 Load to Drive

2. Select the slot number of your choice. The system ignores empty slots. Press the
4 button to increment and the 3 button to decrement.
3. Press the Ok button.
The robot removes the cartridge from the selected magazine slot and moves it to
the drive.
StorageLoader Installation and User Manual
Description
Allows the operator to set a four-digit password protection
for the menu system. The default password is <0000>,
meaning the password is disabled.
Ok
Load to drive
From Slot: 35
1
3
Operation and Configuration
Cancel
4
35
