1. A "?" when status is unknown and Inventory is still running.
2. A number indicates a slot occupied by a cartridge (figure 2.3 shows how the
cartridge slots are numbered in the magazines)
3. Underscore line indicates an empty slot
4. 'C' indicates that a Cleaning Cartridge occupies the slot.
The line below the map on the default screen gives the drive status. The drive status
displayed is drive dependent.
Line 2
Line 3

Figure 4.3 The Default screen

The robot operation status has the following options:
1 Idle
2 Fetching
3 Stowing
4 Moving
Table 4-1 Robot Operation Statuses
22
Robot operation status
Idle
Map: __ 3 _ 5 _ 7 _
Drive Empty
The loader is idle
The loader is moving a cartridge from a magazine slot or from
the drive to the robot.
The loader is moving a cartridge from the robot to a magazine
slot or to the drive.
The loader is moving the robot.
Operation and Configuration
Menu button
Soft Label
Menu
