The self-test display reflects the system configuration listed in Table 6-3 and
Table 6-4. Each numbered item in the example is explained in Section 6.11 through
Section 6.15. These sections assume the same system configuration (see Section
6.16.1 for the results of the show configuration command for this example).
Table 6-3 System Configuration for Example 6-4
Module
KN7CD-AB
KN7CD-AB
MS7CC
KFTHA
KFTIA
Table 6-4 I/O Subsystem Configuration for Example 6-4
Module
KFTIA
I/O Channel C0
I/O Channel C1
KFTHA
I/O Channel C4
I/O Channels C5, C6
I/O Channel C7
PCI/EISA
TLSB
Node # Module Type
0 Dual processor; CPU0 fails ST2 and ST3 testing.
CPU1 becomes boot processor.
1 Dual processor; passes ST1, ST2, and ST3 testing.
2, 6 Memory (384 Mbytes).
7 I/O adapter leading to I/O channels.
8 I/O adapter leading to one I/O channel.
Node # Module Type
8 I/O adapter
Internal PCI; passes self-test.
FBUS I/O adapter; fails self-test, no devices
reported.
7 I/O adapter
XMI I/O adapter; fails self-test, no devices
reported.
(no devices attached here)
PCI I/O adapter; passes self-test.
1 I/O adapter; passes self-test.
System Troubleshooting 6-21
