2.3 System Front View

With the front door open, you can see the control panel, the TLSB card cage,
blower, PCI shelves, StorageWorks shelves, and power regulators.
Figure 2-3 System Front View
Front
2-6 AlphaServer 8200/8400 Operations Manual
Expander Console
On/Off
Enable
PowerComm 3
External
Enable (XMI/FBUS)
Secure Run
PowerComm 2
External
UPS Power
Restart Fault
PowerComm 1
External
TM
Power Enable
+ 48VDC- + 48VDC-
9 SIGNALS 1
CURRENT
SHARE
10 2
BX-0604B-97
CD-ROM Drive
TLSB
Card Cage
StorageWorks Drive
StorageWorks Power
Supply
Control Panel
Floppy Drive
CCL Panel
StorageWorks Shelves
PCI Shelf
Space for
Power Regulators
