Compaq AlphaServer GS60 Operation Manual page 261

Device name — The name and model of the device as recorded in the device's
firmware.
Device type — Lists the function of the device in the system.
Revision — The revision level of the device signifies the number of times it has
been updated by the manufacturer.
Physical slot — Lists the actual PCI slot number to which the device is attached.
Refer to your system manual for information on the physical location of PCI slot
locations on your particular system board.
You can find additional detail about any of the PCI devices listed in the Advanced
PCI Information screen. Follow this procedure to view this screen:
1. Press Enter to enable selection in the device list.
2. Use the arrow keys to select the device for which you want additional detail.
3. Press Enter, and the detail is displayed.
4. Press Escape to return to the table of PCI devices.
The Advanced PCI Information screen is shown in Figure 8-12 on the next page.
AlphaBIOS Firmware 8-19
