Example 4-3 shows a sample show config SRM command for an AlphaServer 8200
configured with a KFE72 adapter, providing support for a graphics monitor, keyboard
and mouse, serial and parallel ports.
The processor module is located in TLSB slot 4, the lowest-numbered slot on an
8200.
All buses off the KFTHA are PCI buses, as required for an AlphaServer 8200 (or
an 8400 running Windows NT). Note that hose 1 is connected to a KFE72
adapter, taking the first five slots in the PCI bus. Slot 0 contains the standard I/O
module, and slot 4 contains the PowerStorm 3D30 graphics module. Note that the
KFE72 must always connect to hose 1 of the KFTHA or KFTIA (in slot 8 of the
TLSB).
This section is shown for any PCI bus containing a standard I/O module (SIO). It
is not meaningful, however. The keyboard and mouse connectors on a KFE72
adapter occupy slot 2 of a PCI card cage. Slot 1 contains two serial ports, and slot
3 is allocated for a parallel port assembly.
I/O Subsystems 4-13
