1.3 System Architecture

The high-speed TLSB system bus is used to interconnect processors, memory
modules, and I/O port modules.
Figure 1-3 Sample System Architecture
Processors
Memory
System Bus
I/O
I/O Bus
Port
Adapter
I/O Bus
I/O I/O I/O
Controller Controller Controller
Devices
Devices Devices
BX0501-94
1-6 AlphaServer 8200/8400 Operations Manual
