Table 2-3 Control/Status and I/O Connections
Connector Name
Console
Expander
Power Comm3
Power Comm2
Power Comm1
External Enable XMI /FBUS+
External UPS Power
External Power Enable
Function
Serial console device connection for
OpenVMS, DIGITAL UNIX, and
Windows NT systems.
(For Windows NT systems, the graphics
monitor is connected through the KFE72
adapter installed in the primary DWLPB
adapter (connected to hose 1 on the
KFTHA or KFTIA in slot 8 of the TLSB).
Expander cabinet power supply control
connection.
NOTE: The expander cabinet connector is
not intended to be connected to a public
telecommunications network.
Reserved for future use.
Power supply 2 signal and control
connection.
Power supply 1 signal and control
connection.
Reserved for future use.
Battery backup option connection.
Enables power to PCI and StorageWorks
shelves.
AlphaServer 8200 System 2-13
