8.5.7 Integrated Peripherals

Figure 8-16 Integrated Peripherals
Systemboard Configuration
Hard Disk Configuration
PCI Configuration
EISA Configuration
SCSI Configuration
Memory Configuration

Integrated Peripherals

1
Serial Port 1: Enabled as COM1:
Serial Port 2: Enabled as COM2:
Parallel Port 1: Enabled as LPT1:
Device type — The physical device as it exists on the system board.
MS–DOS name — Shows if the device is enabled, and if it is enabled, the
addressable MS-DOS name for the device.
Port address — The physical memory location from and to which data travels as it
is received into the device, and sent from the device, respectively.
Interrupt — The interrupt request line (IRQ) used by the device to get the CPU's
attention.
Display System Configuration
2 3 4
3F8, IRQ17
2F8, IRQ10
3BC, IRQ11
BX-0581-98
AlphaBIOS Firmware 8-25
