Compaq AlphaServer GS60E Quick Specification

A A G
T L A N C E
GS60E systems offer superior
business and technical application
performance with large I/O
capacity to tackle the most
demanding enterprise applications
Processor module with two Alpha
21264 6/525-MHz CPUs; each
with 4-MB L2 cache
System I/O module with four I/O
channels
1-GB or 4-GB memory
PCI Shelf Mount Box
10/100 Mb Fast Ethernet network
interface card
UltraSCSI 1-port Single-ended
adapter
UltraSCSI 16-bit StorageWorks
shelf with power supply and 1-m
SCSI cable
9.1-GB UltraSCSI disk drive
600-MB CD-ROM drive
PCI SCSI controller and 2-m SCSI
cable for connection to
CD-ROM
3-phase power system with power
cord
Redundant 48 VDC hot
swappable power supplies to
power CPU, memory, I/O, and
PCI shelves
120 VAC power for StorageWorks
shelves
Shielded console cable for
connection to console terminal
Tru64 UNIX or OpenVMS
Factory Installed Software
90-day software product warranty
Protected by Compaq Services,
including one-year, on-site, four-
hour response warranty; system
installation must be ordered
separately
Q S
UICK
Overview
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
1. CPU module (front)
. .
. .
2. Memory module (front/rear)
. .
. .
. .
3. I/O module (rear)
. .
. .
4. Blowers
. .
. .
5. CD-ROM and optional diskette drive
. .
. .
6. PCI box (rear mount)
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
.
1
DA-10352-00A-001
PECS
Compaq AlphaServer GS60E
7. Space for second PCI box
8. StorageWorks shelf
9. Space for second StorageWorks shelf
10. 48 VDC power regulator (3)
11. AC distribution panel
12. Door and operator control panel (OCP)
