Programming manual

Flag 3 - Receipt consecutive number, cash register number

Figure 3.3. Third system flag values
Digit Default setting
1 0
2 – 3 01
4 – 7 0001

Flag 4 - Required operations

Figure 3.4. Fourth system flag values.
Digit Default setting
1 1
2 0
3 0
4 0

Flag 5 a) - Communication with PC and payment terminal

Figure 3.5. a) Fifth a) system flag values.
Digit Default setting Meaning
1 5 PC port number
Programming of communication speed for the PC.
2 1
Parity: none, DataBits: 8, StopBits: 1
3 0 Data transmission direction in PC-ON LINE mode
4 0 Payment terminal port number
5 0 Communication protocol for payment terminal
Two and more devices can´t be assigned in F5a) and F5b) to the same serial port. Port no. 5 (USB) and 6 (RS-485) shares
pins with COM2 port. Only one device can be connected to the same port.

Flag 5 b) - Scanner and scales configuration

Figure 3.5. b) Fifth b) system flag values.
Digit Default setting
1 0
2 3
28
Meaning
Receipt consecutive number clearing
Cash register number
Receipt consecutive number
Meaning
Subtotal amount print out after Subtotal key is pressed
Required Subtotal key pressed before receipt is finished
Required Credit Card number entering if paid by Credit
Required customer's payment amount entering
Meaning
Scanner port number
Bar code scanner communication speed
Valid values
0 – after "Z" total (daily) report,
1 – after "Z" periodical report
(01 – 99)
(01 – 9 999)
Valid values
0 – no, 1 – yes
0 – not required,
1 – required
0 – not required,
1 – required
0 – not required,
1 – required
Valid values
0 – device is not used
1..4 – RS-232 port number (COM1-COM4)
5 - USB port
6 – RS-485 interface on COM2
0 – 9 600 Bd
1 – 38 400 Bd
0 – PC transmits
1 – PC transmits and receives
0 – device is not used
1..4 – RS-232 port number (COM1-COM4)
0 - Dionica
1 - Bull
Valid values
0 – device is not used
1..4 – RS-232 port number (COM1-COM4)
0 – 1 200 Bd
1 – 2 400 Bd
2 - 4 800 Bd
3 - 9 600Bd
4 - 19 200Bd
