Cash register characteristics
Dimensions [mm]
Weight
Power
Accumulator
Power saving mode
Power consumption
Optional accessories
Standard specifications

Peripheral devices

The optional external devices are plugged into connectors that are shown in figure 2.4.
Recommendation: Ask your cash register dealer on the possibilities for connecting optional external devi-
ces to the ECR.
Cash drawer
Power adapter 230/24V
External keyboard
16
315 x 275 x 115 mm
2,2 kg
adapter 230 V AC/12 V DC
2× NiMH 7,2 V/1600 mAh
yes
7W
cash drawer, digital scales, scanner, payment terminal, external keyboard,
external PC keyboard, built-in programmable keyboard, external battery
box with car lighter cable, car lighter cable, expansion module with two
RS 232 ports, UV LED module for banknotes checking, RS-232/Ethernet
interface, memory expansion to 10 000PLU
EN 55024, EN 61000-4-2, 3, 4, 5, 6, EN 61000-3-2, 3, EN55022 - class B
Figure 2.3 – External equipments for Euro-200T/TX.
Bar-code scanner
PC keyboard
Payment terminal
USB Slave 2.0
Digital scales
PC
USB
RS-485
RS-232
Modem
RS-232
Ethernet
communication module
PC
PC
