Optional ECR accessories

Cash drawers

The cash register Euro-2100TE allows connection of majority of cash drawers
that are based on solenoid opening mechanism (12-15V; 1,2A / 24V; 1,5A).
The electronic cash register is equipped with cash drawer interface by de-
fault.
The cash drawer is connected to the electronic cash register via a cable
that enables its automatic opening. The cable and the connector is easily
detachable. Small establishments will surely welcome the possibility to pla-
ce the cash drawer anyplace they wish and open it automatically using the
electronic cash register.
Ask your authorised Euro-2100TE dealer on delivery and installation of cash
drawers.

Bar-code scanners

Interface for connecting bar-code scanners is a default feature of the cash re-
gisters Euro-2100TE. In case you wish to use bar-code scanners, this chapter
will help you select the bar-code scanner suitable for your establishment. In
any case, we recommend consulting this decision with your authorised Euro-
2100TE dealer.
The bar-code scanner is connected to the electronic cash register via the stan-
dard RS-232 interface. The same interface must be available on the bar-code
scanner. The electronic cash register supplies +5 V DC voltage to power the
bar-code scanner. Both the ECR and the scanner must be programmed appro-
priately in order to work together properly.
Metrologic bar-code scanners are the recommended option for the cash registers Euro-2100TE. Ask your
authorised Euro-2100TE dealer on further information for bar-code scanners.
104

Electronic scales

The cash register Euro-2100TE allows connection of multiple types of electronic
scales. The scales are usually equipped with the serial interface that enables
them to co-operate with the cash registers Euro-2100TE. It is possible to connect
two scales in the same time to the Euro-2100TE. You can use electronic sca-
les also, without connection to the Euro-2100TE. The electronic scales that are
delivered with the cash registers Euro-2100TE are certified and equipped with
a communication cable upon request.
Ask your authorised Euro-2100TE dealer on delivery and installation of electronic
scales.

Metrologic MS-5145 ECLIPSE

Scanning after pressing a trigger, hand scanner without stand, power
supply 5 V, 72 lines/s, scanning range 140 mm, RS-232 interface (mo-
del 5145 R).
