Troubleshooting

Diagnostic Tools

Diagnostic Tools

Diagnostic Features
Feature
PingTest
Link Test
Display Config File
Admin. and Troubleshooting
Commands
Factory-Default Config

Ping and Link Tests

The Ping test and the Link test are point-to-point tests between your switch
and another IEEE 802.3-compliant device on your network. These tests can
tell you whether the switch is communicating properly with another device.
N o t e
To respond to a Ping test or a Link test, the device you are trying to reach must
be IEEE 802.3-compliant.
Ping Test. This is a test of the path between the switch and another device
on the same or another IP network that can respond to IP packets (ICMP Echo
Requests).
Link Test. This is a test of the connection between the switch and a desig-
nated network device on the same LAN (or VLAN, if configured). During the
link test, IEEE 802.2 test packets are sent to the designated network device
in the same VLAN or broadcast domain. The remote device must be able to
respond with an 802.2 Test Response Packet.
11-14
Default Menu
n/a —
n/a —
n/a —
n/a —
page 11-20 —
(Buttons)

CLI

Web
page 11-16 page 11-15
page 11-16 page 11-15
page 11-18 page 11-18
page 11-19 —
page 11-20 —
