Advanced menu

Physical left margin (Physlm)

Physlm
Back Next
1 2 3 4
Physlm= 0/10" *
Set < > Exit
1 2 3 4

Bidirectional parallel interface (CX-bid)

Paphand CX-bid
Back Next
1 2 3 4
CX-bid=On *
Set < > Exit
3
1 2 4
88
Select the Physlm menu (2).
Online
Setup
Setting options: 0 to 30 in 1/10 inch steps
Default setting:
Online
Permanent (physical) setting of the left margin. This parameter can-
not be changed by emulation-dependent margin settings. Margin
Setup
setting values entered by ESC sequences are added to the Physlm.
Note that this value is subtracted from the maximum printing
width of 8 Inches (narrow printer) or 13.6 inches (wide printer).
Confirm the setting by pressing the Set (1) key.
All parameters described in the Paphand group may also be
defined via an ESC sequence (see
Programmer's Application
Press the Next key (4) to access the next group of parameters.
Select the CX-bid menu (3).
Online
Setup
Setting options: On/Off
Default setting:
Online
CX-bid = ON sets the parallel interface of the printer to bidirectional
mode (IEEE 1284, Nibble mode), e.g. for Windows Plug & Play.
Setup
CX-bid = OFF sets the interface to compatibility mode in order to en-
sure reliable operation with special external boxes.
Confirm the setting by pressing the Set (1) key. Change to the next
parameter group with the Next key (4).
0/10 Inch
Emulations
Manual).
On
User guide
(page 125) or
