Menu handling

Save settings

You can navigate in the current menu using the four function and se-
lection keys arranged below the LC display field. Each function and
parameter displayed in the LCD is executed or selected by the cor-
responding key below, respectively. Usually two parameter groups
are combined at one level. In the following example, these are the
LPI and Skip parameter groups.
If you do not wish to change one of the two parameters you can ei-
ther press the Next key (to access the two following parameter
groups in the menu), or you can press the Back key (to access the
two previous parameter groups in the menu).
If you want to change a setting, (e.g. the line density), then press the
LPI key (LPI = lines per inch) to access the actual parameter level.
The currently valid setting is marked by a
the current setting is 6 lpi). With the < and > keys you can view the
other parameters available for this setting.
Example:
back to the previous
parameter groups
6 LPI
Set <
Once the desired parameter is displayed on the LC display, you can
save it by pressing the Set key. The parameter is then set and the
printer automatically displays the parameter groups again. With the
Exit key you can leave the sublevel without saving your changes.
LPI Skip
Back Next
* Skip = 0.0 Inch
> Exit Set
The Menu
* (in the example below
on to the next
parameter groups
*
< > Exit
