Summary of Contents for Dascom 5130P

  • Page 3 Tally Dascom 5130P Important Safety Instructions (English) Read the following instructions thoroughly before starting up your printer. • Never carry out maintenance or repair work yourself. Always contact a qualified service technician. • Keep this Operator’s Manual in a place which is easily accessible at all times.
  • Page 4 Tally Dascom 5130P Wichtige Sicherheitshinweise (German) Lesen Sie bitte diese Sicherheitshinweise durch, bevor sie den Drucker in Betrieb nehmen. • Führen Sie Wartungsarbeiten und Reparaturen keinesfalls selbst aus, sondern verständigen Sie immer einen qualifizierten Servicetechniker. • Bewahren Sie diese Dokumentation an einem jederzeit zugänglichen Ort auf.
  • Page 5 Tally Dascom 5130P Consignes importantes de sécurité (French) Lire attentivement les instructions suivantes avant de mettre l’imprimante en service. • Ne jamais effectuer soi-même les travaux d’entretien et de réparations. Contacter toujours un dépanneur qualifié. • Placer l’imprimante sur un support stable de façon à ce qu’elle ne puisse pas tomber.
  • Page 6 Tally Dascom 5130P Indicazioni di sicurezza importanti (Italian) Prima di mettere in funzione la stampante, leggere attentamente le seguenti indicazioni. Non eseguire mai da sé gli interventi di manutenzione e riparazione, ma rivolgersi sempre a un tecnico di assistenza qualificato.
  • Page 7 Tally Dascom 5130P Instrucciones de seguridad importantes (Spanish) Lea las siguientes instrucciones con esmero antes de poner la impresora en servicio. Nunca lleve a cabo trabajos de mantenimiento o reparación Ud. mismo, sino consulte a un técnico de servicio calificado.
  • Page 8 Tally Dascom 5130P Правила по технике безопасности. (Russian) Прочитайте, пожалуйста, инструкцию по технике безопасности перед включением в работу принтера. • Не выполняйте технические работы и ремонт техники самостоятельно, но сообщайте о неисправностях квалифицированным сервисным техникам. • Данная инструкция должна быть всегда доступна каждому пользователю.
  • Page 9 Tally Dascom 5130P Instruções Importantes sobre Segurança (Portuguese) Leia as instruções de segurança antes de usar a impressora. • Consulte sempre um técnico qualificado para executar uma reparação . • Coloque a impressora sobre uma base sólida e nivelada, para que ela não sofra quedas.
  • Page 10 Tally Dascom 5130P Önemli Güvenlik Talimatları (Turkish) Lütfen, yazıcıyı işletime geçirmeden önce bu güvenlik talimatlarını bütünüyle dikkatle okuyun. • Bakım ve tamir çalışmalarını kesinlikle ve hiçbir surette kendi başınıza yapmayın; her zaman kalifiye bir uzman servis-teknisyenine haber verin. • Yazıcıyı, üzerinden yere düşmesi mümkün olmayacak sabit ve düz bir zemine yerleştirin.
  • Page 11 Tally Dascom 5130P TRADEMARK ACKNOWLEDGEMENTS “IBM” is a trademark of International Business Machines Corporation. “EPSON” is a trademark of Epson America Incorporated. “DEC” is a trademark of Digital Equipment Corporation. “Centronics” is a trademark of Centronics Data Computer Corporation. “DOS” is a trademark of Microsoft Corporation.
  • Page 12 Tally Dascom 5130P...

  • Page 13: Table Of Contents

    4.6.7 IBM Emulation..........................39 4.6.8 Olivetti Emulation ........................40 5 CALIBRATIONS ...........................41 Print Alignment ..........................42 Setting TOF...........................42 Setting Left margin........................43 Setting Tear-off position (optional, only for 5130P with tractors) ...........44 6 TROUBLESHOOTING AND MAINTENANCE..................45 Troubleshooting..........................45 Care and maintenance .........................48 7 SPECIFICATION...........................49 7 .1 Printer specification........................49...
  • Page 14 Tally Dascom 5130P 8 CHARACTER SETS AND CODE PAGES .....................60 Character sets..........................60 International character set commands for Epson emulation ............64 International character sets for Epson emulation .................64 Character tables for Epson emulation ..................65 Code page commands for Epson emulation ................67 Code page tables for Epson, IBM and Olivetti emulations ............69...

  • Page 15: Printer Installation Guide

    Tally Dascom 5130P 1 Printer installation guide 1.1 Unpacking the printer Open the packaging, lift the printer out of the cardboard box and remove the remaining packaging material. Check the printer for any visible transport damage and missing items. If you find any transport damage or any accessories are missing, please contact your dealer.
  • Page 16 Tally Dascom 5130P Remove the packaging material from the printer as follows: 1-2: Remove all the visible tapes from the outside of the printer. 3: Open the printer front cover. 4: Remove the transparent cover. 5: Remove the cable ties from the left and right ends of the carriage shaft.

  • Page 17: Placing The Printer

    Tally Dascom 5130P 1.2 Placing the printer Place the printer on a solid, flat, stable surface; ensuring that the printer is positioned in such a way that it cannot move, and that there is easy access to the control panel and paper input devices. Also ensure that there is enough space for sufficient ventilation and for the printed output.

  • Page 18: Printer Components

    Tally Dascom 5130P 1.3 Printer components Printer components and functions are shown as below:...
  • Page 19 Tally Dascom 5130P Component Function Cover Protects print head and other components inside, and reduces noise. Control panel Shows printer status for printer function setup. Power switch Powers printer ON or OFF . Paper loader Paper feed path for single ply and bankbook/passport...

  • Page 20: Installing And Removing Ribbon Cartridge

    Tally Dascom 5130P 1.4 Installing and removing ribbon cartridge Installing ribbon cartridge 1. Ensure the printer is powered off. 2. Press the recesses of both sides to open the cover. Remove the transparent cover. 3. Push the control lever to lift up the top of mechanism, and make sure the control lever is set to the latched position.
  • Page 21 Tally Dascom 5130P 5. I nstall the recess positions on the ribbon cartridge into the printer mounting, and push both sides of the ribbon cartridge to ensure they click into position. 6. Press the ribbon guides onto the print head from underneath until it clicks into position.
  • Page 22 Tally Dascom 5130P 8. Pull down the control lever to set the top of mechanism to the original position, and make sure the control lever is fully latched. 9. Install back the transparent cover to reduce noise. 10. Close the cover carefully. When the printer is in operation, ensure the cover is closed to keep the dust...
  • Page 23 Tally Dascom 5130P Removing ribbon cartridge 1. Eject any loaded paper in the printer and turn off the printer. To prevent electrical damage to the printer, do not replace the ribbon cartridge when the power is on. 2. Open the cover and move the carriage to the middle. Be careful not to touch the print head if printing had just been performed, as the print head may be hot.

  • Page 24: Connecting The Interface Cable

    Tally Dascom 5130P 1.5 Connecting the interface cable The parallel, serial and USB interface ports are located at the rear of the printer. Choose the interface which suits your system. Note: Make sure the printer and the computer are switched off before connecting or disconnecting the interface...

  • Page 25: Connecting The Mains Power

    Tally Dascom 5130P 1.6 Connecting the mains power Checking the printer voltage Make sure that the device has been set according to your country’s power supply voltage. To do this, check the rating plate at the rear of the printer. Contact your dealer if the setting is incorrect.

  • Page 26: Installing The Printer Driver

    Tally Dascom 5130P 1.7 Installing the printer driver Installing the Windows Driver (Compatible with Windows 2000/2003/2008 Server/XP/Vista/7) Note: Power off the printer before running the printer driver setup. Your printer CDROM comes with Windows drivers. Go to the Drivers folder and run the Installer “DriverSetup.exe”.
  • Page 27 Tally Dascom 5130P Select the desired printer model as shown as below. Click “Next” to continue. Here you can choose whether to set the driver as the system default driver, and whether you want to print the Test Page after installation is completed. If the driver had been installed before, it would be listed in the white box as below.
  • Page 28 Tally Dascom 5130P Click “Finish” to start the installation process. After installation is completed successfully, you will see the message as below.

  • Page 29: Paper Installation Guide

    2）multilayer paper, up to 1+4 copies 3）bankbook and passport 4）continuous paper, up to 1+4 copies (only for 5130P with tractors) Note: Please select the correct media in “System Setup” in Setup Menu mode, so as to prevent paper jam or damage to the print head.
  • Page 30 Tally Dascom 5130P Printable area specifications: Single ply Printable area Printable area of single ply Position Dimension Definition Min. 4.23 mm Top margin Min. 3.12 mm Right margin Min. 5 mm Bottom margin Min. 3.12 mm Left margin...
  • Page 31 Tally Dascom 5130P Bankbook / Passport Bankbook-H / Passport-H (Horizontal-Binding) Printable area Printable area Printable area of bankbook-H / passport -H (Horizontal-Binding) Position Dimension Definition Min. 5 mm Top margin Min. 5 mm Right margin Min. 5 mm Center margin Min.
  • Page 32 Tally Dascom 5130P Continuous paper (with optional tractors) Printable area (First page) Printable area (Last page) Printable area of continuous paper Position Dimension Definition Min. 3.2 mm Top margin Min. 25.4 mm Right margin Min. 6 mm Center margin Min. 6 mm Center margin Min.

  • Page 33: Friction Feed Handling

    Tally Dascom 5130P 2.2 Friction feed handling Inserting a single ply 1. Upon power-on, all of the five LEDs turn on briefly. After initialization, only LED“ON/PAPER” retains on in Olivetti emulation. In Epson ESC/P2 and IBM emulation, LED“USER1” and LED“OFFLINE” retains on while LED“ON/PAPER”...

  • Page 34: Tractor Feed Handling (Optional, Only For 5130P With Tractors)

    Tally Dascom 5130P 2.3 Tractor feed handling (optional, only for 5130P with tractors) 1. Upon power-on, all of the five LEDs turn on briefly. After initialization, only LED“ON/PAPER” retains on in Olivetti emulation. In Epson ESC/P2 and IBM emulation, LED“USER1” and LED“OFFLINE” retains on while LED“ON/PAPER”...

  • Page 35: Control Panel Operation

    Tally Dascom 5130P 3 Control panel operation 3.1 Keys and LEDs There are three keys on the control panel: 【USER1】/【LOAD/EJECT】,【OFFLINE】and【USER2】/【TEAR LF/FF】. It consists of five LEDs: DATA, ON/PAPER, USER1, OFFLINE and USER2, with LED“ON/PAPER” in green and other 4 LEDs in orange.
  • Page 36 IBM emulation Menu 1 is loaded. Menu 1 is not loaded. Printer receives data. Signals to press USER1 Olivetti Auto assignment or as 5130P is granted to emulation assigned to teller 2. teller 1. “USER2” BLINK Epson ESC/P2 Menu 2 is loaded.
  • Page 37 Tally Dascom 5130P Keys 【USER1】 / 【USER2】 / 【OFFLINE】 【LOAD/EJECT】 【TEAR LF/FF】 Online Mode Online Mode Friction feed path selected: Friction feed path selected: - If paper is not loaded, Pressing this key has no pressing this key has no effect.
  • Page 38 Tally Dascom 5130P 【USER1】 / 【USER2】 / 【OFFLINE】 【LOAD/EJECT】 【TEAR LF/FF】 1.Toggles online/offline, if Press once to response to Press once to response to empty buffer. operator assignment as operator assignment as Olivetti 2.During printing, sets indicated by indicated by emulation offline (LED“OFFLINE”=On)

  • Page 39: Power-On Functions

    Tally Dascom 5130P 3.2 Power-on Functions Holding down a key or a combination of keys while powering on the printer, some special functions can be implemented. Please note that power-on functions are not supported by optional tractor feed handling. Self Test 1 Hold 【USER1】...
  • Page 40 Tally Dascom 5130P Self Test 2 Hold 【OFFLINE】 while powering on till the printer resets to activate the self test and beeps twice. Load an A4 paper to start the self test printing. LED“DATA” and LED“ON/PAPER” light up. Below is part of the printout of endless running ASCII TREE.
  • Page 41 Sometimes it is necessary update the firmware to solve a problem. The latest firmware file may be obtained from your dealer or downloaded from our website www.dascom.com. Before upgrading firmware, it is strongly recommended to print the menu page to keep a record of the old settings.
  • Page 42 Tally Dascom 5130P 3) Go to DOS prompt window, type in “copy/b <file name> lpt1” , and press enter to start. During download, LED”DATA” and LED “USER1” blink, while other LEDs light up. 2. In Linux operation system 1) Connect the printer to PC with parallel cable or USB cable.
  • Page 43 Tally Dascom 5130P Calibrations With the cover open, hold 【USER1】+【OFFLINE】+【USER2】 while powering on the printer. It beeps once after implementing the paper detection action, while LED”DATA” blinks and other LEDs light up, to indicate the activation of Calibrations mode. This mode provides the following functions: Print alignment, Setting TOF , Setting left margin and Setting tear-off position (for continuous forms only).

  • Page 44: Setup Menu

    Tally Dascom 5130P 4 Setup Menu With the cover closed, hold 【USER1】 + 【USER2】 while powering on till the printer resets to enter Setup Menu mode and beeps 3 times. Note: Setup Menu can be implemented easily with Configuration Tool which comes on the CD-ROM enclosed with the printer.

  • Page 45: Enable/Skip Listing Current Settings

    Tally Dascom 5130P 4.1 Enable/Skip listing current settings 1) With the cover closed, hold 【USER1】 + 【USER2】 while powering on until the printer resets and beeps 3 times. LED”DATA” lights up and LED”ON/PAPER” blinks to indicate the activation of Setup Menu mode.

  • Page 46: Copy Menu

    Tally Dascom 5130P Copy Menu 1) With the cover closed, hold 【USER1】 + 【USER2】 while powering on until the printer resets and beeps 3 times. LED”DATA” lights up and LED”ON/PAPER” blinks to indicate the activation of Setup Menu mode. 2) Load an A4 paper. The printer will automatically print as below.

  • Page 47: Common Setup

    Tally Dascom 5130P The following section introduces and explains all the possible menu settings. The default setting is marked by an asterisk (*). 4.6.1 Common Setup Parameter Parameter Possible Description group settings Common Language English * Selects the menu language.

  • Page 48: System Setup

    Tally Dascom 5130P 4.6.2 System Setup Parameter Parameter Possible settings Description group System Emulation ESC/P2*(Menu1) Selects the emulation for the printer. Setup Olivetti*(Menu2) T5023 No * Selects if the printer is compatible to the T5023 printer or not. Compatible Buzzer No * Selects if the buzzer sounds on hardware errors or not.

  • Page 49: Page Setup

    Tally Dascom 5130P 4.6.3 Page Setup Parameter Parameter Possible Description group settings Page Line 1/6” * Sets the line density in lines per inch. Setup Space 1/3” 1/6=6 lines per inch 1/4” 1/3=3 lines per inch 1/5” 1/4=4 lines per inch 1/7”...
  • Page 50 Tally Dascom 5130P edge of the document. Right: the right edge of the character matrix is aligned to the right edge of the document. Continuous Yes * Selects the handling of paper when the vertical position exceeds Print the form length.

  • Page 51: I/F Emulation

    Tally Dascom 5130P 4.6.4 I/F Emulation Parameter Parameter Possible Description group settings Interface Interface Parallel Selects the interface. Printer can be configured either for Setup Serial*(Menu2) serial, parallel or USB connection. Two interfaces can be used USB*(Menu1) at the same time, one assigned to USER1 and one to USER2.

  • Page 52: Character Emulation

    Tally Dascom 5130P 4.6.5 Character Emulation Parameter Parameter Possible settings Description group Character Font Draft * This parameter selects the character style. The fonts Setup Roman available depend on the installed character generator. Sans Serif Courier Prestige Script OCR B...

  • Page 53: Epson Esc/P2 Emulation

    Tally Dascom 5130P Kamenicky,Mazovia Baltic_775,CRO_ASCII Farsi,Urdu,Greek_DEC ELOT_928,UK_ASCII US_ASCII,Swedish German,Portuguese French,Italian,Norwegian Spanish,Siemens_Turkish DEC_Turkish 4.6.6 Epson ESC/P2 Emulation Parameter Parameter Possible Description group settings ESC/P2 Country US-ASCII * Selects the national character set in Epson emulation. The Emulation France character sets are not necessarily available for all fonts.

  • Page 54: Olivetti Emulation

    Tally Dascom 5130P 4.6.8 Olivetti Emulation Parameter Parameter Possible Description group settings Olivetti Sub-Emulation PR2e * Selects the Olivetti sub emulation. Emulation PR40+ PR54+ 2845 PR40 TOF Only valid for Emulation=PR40+. Sets to Yes, TOF=7mm, No * ignore TOF adjustment. Sets to No, TOF defaults to 4.23mm.

  • Page 55: Calibrations

    Tally Dascom 5130P 5 Calibrations With the cover open, hold 【USER1】+【OFFLINE】+【USER2】 while powering on the printer. It beeps once after implementing the paper detection action, while LED”DATA” blinks and other LEDs light up, to indicate the activation of Calibrations mode.

  • Page 56: Print Alignment

    Tally Dascom 5130P Print Alignment This Alignment compensates mechanical variations causing bi-directional misalignment on printing at various resolutions. Carry out the below procedures to improve the alignments in the sequence of Paper, Thick Paper, Very Thick Paper, Carton. 1) With the cover open, hold 【USER1】 + 【OFFLINE】 + 【USER2】 while powering on the printer. It beeps once after implementing the paper detection action, while LED”DATA”...

  • Page 57: Setting Left Margin

    Tally Dascom 5130P 2) Close the cover, the printer resets. Press 【OFFLINE】, the printer beeps once. All LEDs light up. 3) Press 【USER1】, the printer beeps once. The TOF setting mode is activated. Load an A4 paper. A line of twenty “—”s is printed and ejects the paper.

  • Page 58: Setting Tear-Off Position (Optional, Only For 5130P With Tractors)

    Tally Dascom 5130P Setting Tear-off position (optional, only for 5130P with tractors) 1) With the cover open, hold 【USER1】 + 【OFFLINE】 + 【USER2】 while powering on the printer. It beeps once after implementing the paper detection action, while LED”DATA” blinks and other LEDs light up, to indicate the activation of Calibrations mode.

  • Page 59: Troubleshooting And Maintenance

    Tally Dascom 5130P 6 Troubleshooting and maintenance Your printer is extremely reliable, but occasionally problems may occur. This chapter provides information on some of the common problems you may encounter and how you may solve them. If you encounter problems that you can not resolve, contact your dealer for assistance.
  • Page 60 Tally Dascom 5130P Paper Handling Problems and Solutions Problem Solution • Make sure that the paper covers the paper-out sensor. Paper cannot be loaded or fed. • For continuous forms (with optional tractors), make sure that the paper feed lever is located correctly.
  • Page 61 Tally Dascom 5130P Printer Failures A user cannot generally resolve a problem involving defective printer hardware. Power off and on again the printer to recover any fatal error. If the problem cannot be resolved, contact your dealer or service partner.

  • Page 62: Care And Maintenance

    Tally Dascom 5130P 6.2 Care and maintenance Your printer requires very little care. Occasional cleaning and replacement of the ribbon cartridge are all that is required. Cleaning is recommended approximately every 6 months or 300 hours of operation, whichever is sooner.

  • Page 63: Specification

    Tally Dascom 5130P 7 Specification 7.1 Printer specification Print System Mono-chrome serial impact dot matrix Print Uni-/bi-directional logic seeking for text and graphics (software selectable) Technology Pitch HS Draft Draft 10 CPI 400 CPS* 300 CPS 100 CPS 12 CPI...
  • Page 64 Tally Dascom 5130P For Epson ESC/P2 and IBM emulation: 1. Draft 10, 12, 15, 16.6, 17.1, 20, 24CPI 2. Roman 10, 12, 15, 17.1, 20CPI, Proportional 3. Sans Serif 10, 12, 15, 16.6, 17.1, 20CPI, Proportional 4. Courier 10, 12, 15, 16.6, 17.1, 20CPI, Proportional 5.
  • Page 65 Tally Dascom 5130P 23. ISO_ 8859_2 24. ISO_ 8859_5 25. ISO_ 8859_7 26. ISO_ 8859_9 27. ISO_ 8859_15 28. BRASCII 29. Abicomp 30. Roman_8 31. Coax_Twinax 32. New_437 33. New_Dig_850 34. Old_Code_860 35. Flarro_863 36. Hebrew_865 37. Table_1257 38. Ukraine_866 39.
  • Page 66 Tally Dascom 5130P 1. US_ASCII 2. France 3. Germany 4. Great Britain 5. Denmark 1 6. Sweden Epson 7. Italy International 8. Spain 1 Character Sets 9. Japan 10. Norway 11. Denmark 2 12. Spain 2 13. Latin America 14. Korea 15.
  • Page 67 Tally Dascom 5130P Noise Level Less than 55 dB(A) in 10CPI draft ASCII (Conforming to ISO7779 standard) Temperature Operating: +5 to +40 °C. Storage: -20 to +60 °C Ambient Relative humidity Operating: 10 to 90%RH Conditions (No condensation) Storage: 5 to 95%RH...

  • Page 68: Interfaces

    Tally Dascom 5130P 7.2 Interfaces Parallel interface, serial interface and USB interface are the standard interfaces for the printer. The interface pin assignment is listed below. (The signal with overline indicates low true logic level.） 7.2.1 Parallel interface Parallel interface pin assignment...
  • Page 69 Tally Dascom 5130P BUSY Signal to indicate that the printer is not ready for receiving data. If the host ignores it and continues to send data, the data will be lost. The signal turns to high logic level in the following case: Buffer is full.
  • Page 70 Tally Dascom 5130P mechanical functions before this signal enters ready state, or it may cause damage to the printer. FAULT ¯¯¯¯¯¯ Signal to indicate error condition. Low logic level is effective. The signal turns to low logic level in the...

  • Page 71: Serial Interface

    Tally Dascom 5130P Clock and signal logic level Clock Signal logic level Input: high logic level: 2～5V low logic level: 0～0.8V Output: high logic level: 2.4～5V low logic level: 0～0.4V Parallel interface connector diagram Note: 1. Use a standard parallel interface cable to connect the printer and the computer. The length should not exceed 2 meters.
  • Page 72 Tally Dascom 5130P Serial interface wiring diagram Note: 1. The serial cable length should not exceed 15 meters. 2. Make sure the “Interface Setup” selects serial interface and the settings are the same as PC communication port settings. Shown as below:...

  • Page 73: Usb Interface

    Tally Dascom 5130P 7.2.3 USB interface USB interface pin assignment Signal name Description VBUS +5V power supply data data S.GND ground USB interface connector diagram Note: 1. Use a standard USB interface cable to connect the printer and the computer.

  • Page 74: Character Sets And Code

    Tally Dascom 5130P 8 Character sets and code pages 8.1 Character sets Epson standard character table, italic...
  • Page 75 Tally Dascom 5130P IBM character set 1 IBM character set 2...
  • Page 76 Tally Dascom 5130P OCR-A character set 1 OCR-A character set 2...
  • Page 77 Tally Dascom 5130P OCR-B character set 1 OCR-B character set 2...

  • Page 78: International Character Set Commands For Epson Emulation

    Tally Dascom 5130P 8.2 International character set commands for Epson emulation Country Command ＜ESC＞“R”CHR＄（0） ＜ESC＞“R”CHR＄（1） France ＜ESC＞“R”CHR＄（2） Germany ＜ESC＞“R”CHR＄（3） ＜ESC＞“R”CHR＄（4） Denmark1 ＜ESC＞“R”CHR＄（5） Sweden ＜ESC＞“R”CHR＄（6） Italy ＜ESC＞“R”CHR＄（7） Spain1 ＜ESC＞“R”CHR＄（8） Japan ＜ESC＞“R”CHR＄（9） Norway ＜ESC＞“R”CHR＄（10） Denmark2 ＜ESC＞“R”CHR＄（11） Spain2 ＜ESC＞“R”CHR＄（12） Lat America ＜ESC＞“R”CHR＄（13） Korea ＜ESC＞“R”CHR＄（64）...

  • Page 79: Character Tables For Epson Emulation

    Tally Dascom 5130P 8.4 Character tables for Epson emulation Italic...
  • Page 80 Tally Dascom 5130P Graphic 1 Graphic 2...

  • Page 81: Code Page Commands For Epson Emulation

    Tally Dascom 5130P 8.5 Code page commands for Epson emulation Code Page ESC R Parameter ISO_ 8859-1 ISO_ 8859_1SAP ISO_ 8859_2 ISO_ 8859_5 ISO_ 8859_7 ISO_ 8859_9 ISO_ 8859_15 CRO_ASCII UK_ASCII US_ASCII Greek DEC Swedish German Portuguese Roman_8 Coax_Twinax French...
  • Page 82 Tally Dascom 5130P Urdu Old_Code_860 Flarro_863 Table_865 Siemens Turkish DEC_Turkish Bulgaria_866 Table_858...

  • Page 83: Code Page Tables For Epson, Ibm And Olivetti Emulations

    Tally Dascom 5130P 8.6 Code page tables for Epson, IBM and Olivetti emulations Table_437 Table_737...
  • Page 84 Tally Dascom 5130P Table_850 Table_851...
  • Page 85 Tally Dascom 5130P Table_852 Table_857...
  • Page 86 Tally Dascom 5130P Table_858 Table_860...
  • Page 87 Tally Dascom 5130P Table_861 Table_863...
  • Page 88 Tally Dascom 5130P Table_864 Extended_864...
  • Page 89 Tally Dascom 5130P Table_865 Table_866...
  • Page 90 Tally Dascom 5130P Bulgaria _866 Table_1250...
  • Page 91 Tally Dascom 5130P Table_1251 Table_1252...
  • Page 92 Tally Dascom 5130P Table_1253 Table_1254...
  • Page 93 Tally Dascom 5130P IS0_8859_1 ISO_8859_1SAP...
  • Page 94 Tally Dascom 5130P ISO_8859_2 ISO_8859_5...
  • Page 95 Tally Dascom 5130P ISO_8859_7 ISO_8859_9...
  • Page 96 Tally Dascom 5130P ISO_8859_15 BRASCII...
  • Page 97 Tally Dascom 5130P Abicomp Roman 8...
  • Page 98 Tally Dascom 5130P Coax_Twinax New_437...
  • Page 99 Tally Dascom 5130P New_Dig_850 Old_Code_860...
  • Page 100 Tally Dascom 5130P Flarro_863 Hebrew_865...
  • Page 101 Tally Dascom 5130P Table_1257 Ukraine_866...
  • Page 102 Tally Dascom 5130P Kazakhst_866 Kamenicky...
  • Page 103 Tally Dascom 5130P Mazovia Baltic_775...
  • Page 104 Tally Dascom 5130P CRO_ASCII Farsi...
  • Page 105 Tally Dascom 5130P Urdu Greek_DEC...
  • Page 106 Tally Dascom 5130P ELOT_928 UK_ASCII...
  • Page 107 Tally Dascom 5130P US_ASCII Swedish...
  • Page 108 Tally Dascom 5130P German Portuguese...
  • Page 109 Tally Dascom 5130P French Italian...
  • Page 110 Tally Dascom 5130P Norwegian Spanish...
  • Page 111 Tally Dascom 5130P Siemens_Turkish DEC_Turkish...

  • Page 112: Control Codes Summary

    Tally Dascom 5130P 9 Control codes summary Epson ESC/P2 emulation command list Command Function Beeper Backspace Horizontal Tab Line Feed Vertical Tab Form Feed Carriage Return Double-Wide Printing 1 Line Select Condensed Mode Cancel Condensed Mode Cancel Double-Wide Printing 1 Line...
  • Page 113 Tally Dascom 5130P Command Function ESC 7 Enable Upper Control Codes ESC : Copy ROM to RAM ESC < Select Unidirectional Mode 1 Line ESC = Set MSB to 0 ESC > Set MSB to 1 ESC ? Reassign Graphics Mode...

  • Page 114: Ibm Emulation Command List

    Tally Dascom 5130P IBM emulation command list Command Function Backspace Horizontal tab Carriage return ESC BS Backspace ESC HT Horizontal tab ESC CR Carriage return ESC D Set horizontal tabs ESC X Set horizontal margins ESC d Relative mode inline forward...
  • Page 115 Tally Dascom 5130P Command Function ESC I Set print mode ESC P Proportional space mode ESC S Start subscript or superscript printing ESC T Cancel subscript or superscript printing ESC W Continuous double-wide printing ESC [ - Score select ESC [ @...

  • Page 116: Olivetti Emulation Command List

    Tally Dascom 5130P Olivetti emulation command list Command Function ESC Q nnn mmm ESC Z Define document length ESC J nnn Define left margin ESC T nnn Define top of form " TOF" ESC M nnn Define bottom of form "BOF"...
  • Page 117 Tally Dascom 5130P ESC 2 Reset BIM mode ESC X nnn Set relative horizontal position ESC h 0 n m d0 d1 d2 D1 9 pin DLL D2Dm ESC h 0 n m d0 d1 d2 D1 24 pin DLL...

  • Page 118: Fcc Statement

    Tally Dascom 5130 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: a. This device may not cause harmful interference. b. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 120 DASCOM REPRESENTATIVES GERMANY SINGAPORE (ASIA PACIFIC) DASCOM Europe GmbH DASCOM AP Pte Ltd Heuweg 3 21 Bukit Batok Crescent D-89079 Ulm #29-81, WCEGA Tower Deutschland Singapore 658065 Tel.: +49 (0) 731 2075 0 Phone: +65 6760 8833 Fax: +49 (0) 731 2075 100 Fax: +65 6760 1066 www.dascom.com...
